LB15200 — Battery Powered Underwater Light
A high-performance deep-sea lighting module engineered for submersibles, research platforms and inspection systems operating in extreme underwater conditions. Designed to withstand pressures up to 2000 m depth, the LB15200 delivers consistent, energy-efficient illumination where visibility is most critical.
Overview
The LB15200 is a rugged, battery-powered underwater lighting system designed for deep-ocean exploration and scientific missions. Built to endure extreme pressure and low temperatures, it provides reliable, high-output illumination for submersibles, ROVs, observatories and research instruments.
Featuring efficient LED technology, robust anodized aluminum housing and a high-strength glass/acrylic front window, the LB15200 ensures maximum brightness with minimal power consumption. Its modular design supports various mounting options and easy integration with underwater platforms.
The system is equipped with multi-stage intensity control, USB connectivity and a Li-ion rechargeable power module, enabling flexibility for long-duration missions and data acquisition tasks.
Technical Specifications
| Lumens | 1500 |
|---|---|
| Color Temperature | 5000 K (Cool White) |
| Power | 15 W |
| Dimensions | Ø 90 mm × 496 mm |
| Weight | 3.2 kg |
| Beam Angle | 100° |
| Battery | Rechargeable Li-ion |
| Battery Capacity | 11.4 V, 7.5 Ah |
| Material | AL-6061 anodized body, Glass/Acrylic front |
| Rated Depth | 2000 m |
| Intensity Control | 4-stage adjustable with timer |
| Connectivity | USB 2.0 / USB 3.0 |
| Minimum Operating Duration | 2 hours |
| Software | Deep Light V2.0 (Windows) |
Features & Capabilities
- Deep-rated 2000 m pressure housing
- High-output 1500 lumen LED illumination
- Efficient, low-temperature light emission
- Four-stage dimming with programmable timer
- Rechargeable Li-ion battery system
- USB connectivity for configuration and updates
- Multiple mounting options for ROVs, submersibles and static platforms
Key Applications
- Deep-sea research and biological studies
- Submersible and ROV illumination
- Underwater structure inspection
- Pipeline and seabed survey support
- Fixed underwater observatories
- Low-visibility exploration environments
