CB12200 — Battery Powered Deep-Sea Camera
A fully self-contained deep-sea imaging unit designed for extreme depths up to 2000 meters. Built with a high-resolution 12.3 MP sensor, onboard 4K video recording, and rugged SS316 pressure housing, the CB12200 is engineered for scientific exploration, search & rescue, underwater inspections, and long-duration autonomous documentation missions.
Technical Specifications
| Pixel | 12.3 MP |
|---|---|
| Sensor Resolution | 4056 × 3040 pixels |
| Aperture | F2.8 |
| Lens | 3.6 mm |
| Image Sensor Format | 1/2.3" |
| Video | 4K, 1080P (Jetson Powered) |
| Inbuilt Memory | 60 GB |
| Dimensions | 124 mm × 382 mm |
| Input Voltage | 12 V DC |
| Battery | Li-Ion 14.8 V 20000 mAh |
| Material | SS316 + Glass |
| Rated Depth | 2000 m |
| Field of View | 90° |
| Weight | 25 kg |
| Recording Software | Deep Cam V2.0 (Windows) |
Key Features
- High-resolution 12.3 MP still imaging
- 4K underwater video recording with Jetson processing
- Extreme depth capability rated up to 2000 meters
- Self-powered with large 14.8V 20Ah battery
- Robust SS316 subsea pressure housing
- Ideal for deep-sea research and structural surveys
- Integrated 60 GB solid-state storage
- Standalone, tether-free recording system
Applications
- Deep-sea research expeditions
- Scientific marine biology documentation
- Subsea geological and ecosystem surveys
- Search & rescue and recovery operations
- Autonomous long-duration monitoring missions
- ROV/AUV payload integration
